Ultrafast Recovery Rectifier – MUR2040CTR

Description

Electrical Characteristics (at 25 °C, unless noted)

• Repetitive Peak Reverse Voltage (VRRM): 400 V

• Average Forward Current (IF(AV)): 20 A (per device), typically 10 A per diode

• Surge Current (IFSM): 125 A for 8.3 ms half-sine pulse

• Forward Voltage Drop (VF):

  • ~1.25 V typ at IF=10 A, 25 °C; ≤1.5 V max

  • ~1.4 V at 10 A, 125 °C

• Reverse Recovery Time (trr): ~35 ns

• Reverse Leakage Current (IR): ≤10 µA at 400 V, 25 °C; up to 500 µA at 100 °C
